Cord Ball Pressure Tester
Model: SZ-6805
This tester is used for measuring the heat-endurance and pressure resistance of sheathing of the cord. Testing method is to put the specimen upon a testing stand inside a constant temperature chamber which is predetermined at 125±2℃, and pressed with a ball end in diameter 5 mm for one hour; afterwards take out specimen and put it into cool water for 10seconds.then measure its depth of concavity, It will be qualified if the depth is within 2 mm.

Test Standard

  • GB 2099.1-2008 家用和类似用途插头插座 第1部分:通用要求
  • GB/T 5013.2-2008 idt IEC 60245-2:1998 额定电压450/750V及以下橡皮绝缘电缆第2部分:试验方法
  • UL 62-2010 软线和电缆
  • UL 817-2009 软线组件和电源软线
  • IEC 60884-1-2006 插头插座家用和类似用途第1部分:一般要求
  • DIN VDE 0620-1-2010 家用和类似用途插头和插座连接 第1部分:一般要求

Specifications

Model

SZ-6805

Interior Dimensions

W400×D400×H450mm

Temp. Range

Room Temp.200

Pressed Weight

20N

Dia. of ball end

5mm

Heating Method

Hot-air circulation

Timer

06Hr

Dimension

W910×D550×H990mm

Weight

95kg

Power

1AC220V 2A
