Model

SZ-T80
20/40/70

SZ-T150
20/40/70

SZ-T225
20/40/70

SZ-T408
20/40/70

SZ-T800
20/40/70

SZ-T1000
20/40/70

Volume

80L

150L

225L

408L

800L

1000L

Interior
Dimensions

W400×D400
×H500mm

W500×D500
×H600mm

W500×D600
×H750mm

W600×D800
×H850mm

W1000×D800
×H1000mm

W1000×D1000
×H1000mm

Temp.

Range
Optional

20: -20℃～150℃            40: -40℃～150℃            70: -70℃～150℃

Heating Up

20: -20℃↗100℃≤35min-  40: -40℃↗100℃≤45min    70: -70℃↗100℃≤60min

Cooling Down

20: 20℃↘-20℃≤35min    40: 20℃↘-40℃≤55min     70: 20℃↘-70℃≤80min

Accuracy

±0.5℃

Uniformity

±2℃

Refrigeration System

Two-stage compressor refrigeration system or single stage refrigeration system compression

Interior Material

Stainless steel plate SUS304

Exterior Material

Stainless steel plate SUS304 or paint coating

Insulation

Rigid polyurethane foam + glass wool

Accessories

Viewing window shelves (freely adjustable 2 pcs.) cable prot (Ø50mm), chamber lamp.

Safety Devices

Breaker, refrigerator over-load protection relay, refrigerant high pressure switch, air circulator thermal switch, ceramic fuse, boil dry protector, overheat protector, alarm

Exterior
Dimensions

W920×D870
×H1600mm

W1020×D970
×H1700mm

W1020×D107
0×H1850mm

W1120×D127
0×H1950mm

W1520×D127
0×H2050mm

W1520×D147
0×H2050mm

Power

1∮ AC220V±10% 50±1HZ or 3∮ AC380V±10% 50±1HZ
